□ 규 격

- 측정 방사선 : Alpha, Beta, Gamma

- 검출기 종류 : Zns(Ag) Scintillator

- 측정 범위 : 0 ~ 5,000 cps (α-channel)

                  0 ~ 50,000 cps (β-γ-channel)

- Background : approx. 0.1 cps (α-channel)

                      approx. 10 cps (β-γ-channel)

- Gamma sensitivity at 1 uSv/h(Cs-137) : not detectable

                                                          (α-channel)

                                                          < 100 cps

                                                          (β-γ-channel)

- 효율 : Am-241 21 % (α-channel)

           Pu-239 18 % (α-channel)

           C-14 11 % (β-γ-channel)

           Cl-36 44 % (β-γ-channel)

           Co-60 29 % (β-γ-channel)

           Cs-137 43 % (β-γ-channel)

- 저장 기능 : 1000 measured values with data & time

- Sensitive detector area : 170 cm²

- 측정 온도 : -20°C ~ 40°C (operation)

                  -40°C ~ 60°C (storage)

- 케이스 등급 : IP 53 (IEC 60529)

- 크기 : 240 (L) x 140 (W) x 110 mm (H)

- 무게 : 1300g

□ 옵션사항

1. Wall bracket

2. Power supply & Rechargeable batteries

3. Sample holder with drawer(Wipe test drawer)

4. Test source
